Features:

Power consumption requierments: 5V2A
Dimensions: 10x8cm (4"x3.1"), about 1.2cm (0.5") tall
Compatibility: android, linux FreeBSD System Characteristic
CPU ARM Cortex-A9 quad core @ 1.6Ghz Memory 2GB DDR3 @ 800Mhz
Storage 8GB Nand Flash, Micro-SD SDXC up to 128GB Display and Graphics
GPU Mali400-mp4@533Mhz, OpenGL ES 2.0
Digital Video HDMI 1.4 up to 1080p@60hz
Analog Video AV output
Network LAN 10/100M Ethernet port
WIFI 150Mbps 802.11b/g/n with antenna
Bluetooth： Bluetooth 4.0
I/O
Add LVDS interface(FPC connector at the bottom of the board)
Add touch panel interface
Add CSI interface for camera module Audio S/PDIF, headphone jack
USB HOST 2 USB 2.0 standard A type
USB OTG USB OTG micro-USB connector
Serial Serial Console for debugging
IR Support self defined IR remote
Other
Led 3 programable leds
RTC Support power off alarm
Extend header 80 pins including GPIO, I2C, SPI, Line in, USB 2.0, PWM, ADC, LCD, etc

Specification:



CPU	ARM Cortex-A9 quad core @ 1.6Ghz
Memory	2GB DDR3 @ 800Mhz
Storage	8GB Nand Flash, Micro-SD SDXC up to 128GB
GPU	Mali400-mp4@533Mhz, OpenGL ES 2.0
Digital Video	HDMI 1.4 up to 1080p@60Hz
Analog Video	AV output
LAN	10/100M Ethernet port
WIFI	150Mbps 802.11b/g/n with antenna
Bluetooth	Bluetooth 4.0
Audio	S/PDIF, headphone jack
USB HOST	2 USB 2.0 standard A type
USB OTG	USB OTG micro-USB connector
Serial	Serial Console for debugging
IR	Support self defined IR remote
Key	1 power key, 1 recovery key, 1 reset key
Led	3 programable leds
RTC	Support power off alarm
Extend header	80 pins including GPIO, I2C, SPI, Line in, USB 2.0, PWM,   ADC, LCD, GPS etc
