Cubieboard5 is the 5rd generation product in Cubieboard series from Cubietech Limited. CubieBoard is open source hardware which is easy to use open source hardware/development board that suit for Students, Developer, Geek, Maker…The design intention is not only easy to develop, but also easy to use.
It's a new PCB model adopted with Allwinner H8 main chip (octa cores). Also, it is enhanced with some features, such as 2GB DDR3 memory, DP display port, 100M/1000M RJ45, WIFI+BT (2.4G/5GHz)on-board, support Li-Po battery and RTC battery, SPDIF HD audio interface.
It's not only for development, but also can be used in various areas like other Mini Pc products. Thanks to its rich interfaces, low costs, and good open source support ambient, more and more developers can benefit based on it and would like to do lots of promotion work for it.
It's famous open source hardware, Cubietech offial team will continully maintain Android, Debian, Debian Server operating systems. Many other open source distribution would support it as well.
Linux kenel mainline stream supports it as standard device. We are pleased to participate the community and promote them growing continuously...
· AllWinner SOC H8， ARM® Cortex™-A7 Octa-Core，PowerVR SGX544MP1 Complies with OpenGL ES 2.0/1.1
· 1GB/2GB DDR3@480MHz (960MTPS), 2GB Default
· HDMI&DP 1080P@60Hz display output
· 100M/1000M Ethernet RJ45
· Wifi + BT 4.0 wireless connection with antenna on-board
· SATA 2.0 interface support 2.5' HDD，(for 3.5' HDD, need another 12V power input)
· Storage solution：NAND Flash +MicroSD card slot / TSD + MicroSD card slot / 2*MicroSD card slot
· 2 x USB HOST， 1 x OTG， 1 x Toslink (SPDIF Optical)， 1 x IR， 4 x LEDs， 1 Headphone， 3 x Keys
· Power：DC5V @ 2.5A with HDD， support Li-battery & Real Time Clock battery
· 70 extended pins including I2S, I2C, SPI, CVBS output, Low Resolution ADC x2, UART, PS2, PWMx2, TS/CSI, IRDA, LINEIN&FMIN&MICIN, TVIN analog video signal input x 4 with 2.0mm pitch header pins
· It's suitable for installing a 2.5 inch HDD/SSD within the cases
Cubieboard5 mainboard x1
SATA 2.0 cable x1
Mini USB to OTG x1
Mini USB cable x1
USB to 1.7 mm DC jack cable x1
Ultrathin Heat Sink x1
